ARVIVIEW OEM 10.1"

OVERVIEW

ARVIVIEW DISPLAY OEM PROVIDES A REMARKABLE VIEWING EXPERIENCE WITH ITS GRADE-A IPS PANEL WITH 1024X600 RESOLUTION. ENJOY EFFORTLESS NAVIGATION AND AN IMMERSIVE VISUAL EXPERIENCE WITH THIS RESPONSIVE, USER-FRIENDLY MULTI-TOUCH SCREEN.

• Compact 10.1 inch display, perfect for small spaces. High-quality IPS panel with 16.7M colors, high contrast, and clear images.

• Excellent visibility in low light environments with display's adjustable brightness levels

• Multiple interfaces including Wi-Fi, Ethernet, USB, and HDMI

• Flush mounting

SPECS

DISPLAY

Display Size: 10.1 inches

Display Type: TFT LCM with wide viewing angle Multi-touch

Resolution: 1024x600 pixel

Brightness (cd/m2): 200/1000, 100 levels adjustment

Colors: 24 bits, 16.7 million, 8R8G8B

Viewing Angle: 80/80/100/100 (L/R/U/D); best view: symmetrical

Mounting: Flush mounting

SYSTEM

CPU: ARM Cortex-A55

Memory Type: 2GB LPDDR4

Operating System: Android 11

Storage: eMMC 8GB

ENVIRONMENT & CERTIFICATION

Operating Voltage: 12V, recommended: 12V, 1A

Operating Temperature:-10°C/+60°C, recommended: 25°C

Operating Humidity: 10% / 90%

Temperature: -40°C / 80°C

Certification: CE, FCC, RCM

Interfaces: USB 2.0, Ethernet, Wi-Fi, Bluetooth

Compatible: Microphone, camera and other peripherals

INPUTS/OUTPUTS

Power Supply: 1x 12V ATX input

SD Card: 1x SD card slot

Video: 1x HDMI

Audio: 1x Audio 1/0

Ethernet: 1x RJ-45, 10/100Mbps

USB: 2x 2.0 USB ports, 1x micro USB

Warranty: 3 Years

Dimension: 257.81 (W)x 148.8(H) x 23.20(T) mm.

Net Weight: 620g
